GB - 30
SPECIFICATIONS
Model Number 924335 924336 924337 924338 924516 924517
Description ST926DLE ST11526DLE ST11528DLE ST1332LE ST1332DLE ST1336DLE
Engine - Tecumseh OH318SA OH318SA OH358SA OH358SA
Power Max - HP (kW) 9.0 (6.71) 11.5 (8.6) 13.0 (9.7)
Fast Idle Speed - RPM
(min
-1 )
3600 ± 150
Displacement -
in. (cc) 19.43
(318.3)
21.82
(357.6)
Electric Start 240V 12V
Fuel See Engine Manual
Tank Capacity -
qt (Liters)
4 (3.8)
Snow Clearing Width - in.
(cm)
26 (66.0) 28 (71.2) 32 (81.3) 36 (91.4)
Chute
Rotation Angle 220°
Rotation Control at
Handlebar
Yes No
Remote Deflector Control Yes
Impeller
Diameter - in. (cm) 14 (35.6)
Speed - RPM-Max (min -1 ) 1209
Auger
Diameter - in. (cm) 16 (40.6)
Speed - RPM-
Max (min
-1
)
121
Auger Brake Yes
Attachment Clutch Yes
Drive Disc-O-Matic
Speeds 6 Forward and 2 Reverse
Lock Out Differential Yes Pin-Lock Yes
Pneumatic Tires - in.
(cm) 16/4.80 x 8
(40.6/12.2x20.3)
16/6.50 x 8
(40.6/16.5x20.3)
Size and Weight
Length - in. (cm) 60 (152)
Height - in. (cm) 45 (114.3)
Width - in. (cm)
28.5 (72.4) 30.5 (77.5) 34.5 (87.6)
38.5
(97.8)
Weight - lbs (Kg)
281 (127.5)
289
(131.0)
335 (151.9)
337
(152.9)
