xi
P5NSLI and P5NSLI/WiFi specifications summary
(continued on the next page)
CPU
Chipset
Front Side Bus
Memory
Expansion slots
Scalable Link
Interface (SLI™)
AI Audio
Storage
Gigabit LAN
USB
LGA775 socket for Intel ® Core™ 2/Intel ® Pentium D/
Intel ® Pentium ® 4/Intel ® Celeron ® processors
Compatible with Intel ® PCG 05B/05A/06B processors
Supports Intel ® Enhanced Memory 64 Technology (EM64T)
Supports Enhanced Intel SpeedStep ® Technology (EIST)
Supports Intel ® Hyper-Threading Technology
North Bridge: NVIDIA ® C19 SLI
South Bridge: NVIDIA ® MCP 51
1066/800/533 MHz
Dual-channel memory architecture
4 x 240-pin DIMM sockets support unbufferred non-ECC
DDR2-667/DDR2-533 memory modules
Supports up to 16 GB system memory
2 x PCI Express x16 slots with Scalable Link Interface
(SLI™) support
3 x PCI Express x1 slots
2 x PCI slots
SLI™ mode supports:
- 2 x identical SLI™-ready PCI Express x16 graphics cards
(Note: In SLI mode, the PCI Express x16 slots work at the
bandwidth of PCI Express x8. The combined bandwidth of
these maintain the bandwidth of PCI Express x16.)
Single card mode supports (default):
- 1 x PCI Express x16 graphics card on the first slot
(blue)
- 1 x PCI Express x1 card on the second slot (black)
ASUS EZ Selector
ASUS Two-slot thermal design
ADI ® AD1986A SouldMAX 6-channel CODEC
1 x Coaxial S/PDIF out port
Supports Audio Sensing and Enumeration Technology
NVIDIA ® MCP 51chipset supports:
- 2 x Ultra DMA 133/100/66/33
- 4 x Serial ATA 3Gb/s devices
- RAID 0, RAID 1, RAID 0+1, RAID 5 and JBOD
configuration
Marvell 88E8001 PCI Gigabit LAN controller
Supports AI NET2 network diagnosis before entering OS
Supports up to 8 USB 2.0 ports (P5NSLI model only)
Supports up to 7 USB 2.0 ports (P5NSLI/WiFi model only)
