Accessories
Wireless Headphones
The VOH684 includes a built-in infrared transmitter
and Audiovox wireless headphones (Part Number
IR2CHS-(Two Channel). The volume can be adjusted
with the control on each headset. The wireless
headphones must be used within a line of sight from
the transmitter, as infrared transmissions, like visible
light travel only in a straight line.
Headset Special Features
-Dual Channel.
-Automatic Level Control prevents input
signal over loading.
-Uses high frequency infrared light to assure
a clean signal for clear reception.
1. INFRARED PICKUP SENSORS – (Receives
signals from transmitter)
2. BATTERY COVER
3. VOLUME CONTROL
4. POWER SWITCH
5. POWER INDICATOR LED
6. CHANNEL A/B SWITCH
7. AUTO ON/OFF MICRO SWITCH
Controls and Indicators (Fig.1)
Auto ON/OFF Micro Switch is activated when headphones are
placed on head (shown below)
1
2
5
3
L
R
4
6
7
Fig. 1
