Physical Description
8-slot unit
> Height: 10 VU, 44.5 cm (17.5 in.)
> Width: 48 cm (19 in.)
> Depth: 46 cm (18 in.)
> Rack-mount or desktop unit: 58 cm (23 in.)
or 48 cm (19 in.)
6-slot unit
> Height: 6 VU, 26.5 cm (10.5 in.)
> Width: 48 cm (19 in.)
> Depth: 46 cm (18 in.)
> Rack-mount or desktop unit: 58 cm (23 in.)
or 48 cm (19 in.)
Synchronization Sources
> BITS 1.544 MHz or G.703 2.048 MHz
external
> Line derived
> Stratum 3-compliant
> 50 ppm SSU
Maintenance
> Dual bank flash for fail-safe software
upgrade
> Alarm logs and remote alarm signaling
> Performance monitoring with threshold
crossing alerts
> ATM layer OAM (F4/F5) support
> Operational and diagnostic LED displays
> Circuit, equipment and line loopbacks
> Test access connections
> Network inventory support from Alcatel
5620 NM
Operating Environment
> 0 C to 40 C (32 F to 104 F)
> 5% to 95% relative humidity,
non-condensing
> 60 m (197 ft.) below sea level to
1,800 m (5,905 ft.) above sea level
Product Compliance
> EMC
• FCC Part 15
• Industry Canada ICES-003
• EN 55022
• EN 50082-1
• EN 300 386
• GR-1089-CORE
• PEC-1992-002
• AS/NZS 3548
> Safety
• CSA C22.2 No. 950
• UL 1950
• EN 60950
• IEC 60950
• AS/NZS 3260
• TS 001
• PEC-1992-002
> Environmental
• GR-63-CORE (NEBS Level 3)
> Network attachment
• FCC Part 68
• Industry Canada CS-03
• GR-253-CORE
• ANSI T1.105.03
• ANSI T1.105.06
• ANSI T1.102
• ANSI T1.403
• ANSI T1.404
• ITU-T G.703
• ITU-T G.707
• ITU-T G.823
• ITU-T G.824
• ITU-T G.825
• ITU-T G.957
• ACA TS 016
• ACA TS 026
• JATE (Green Book)
• PEC-1992-002
Power
> Autoranging 100 V/240 V AC
power supply
> -48 V/-60 V DC power supply
> Maximum power consumption
• 6-slot: 450 W
• 8-slot: 880 W
> Typical power consumption: 250 W
> Optional n + 1 redundant power supply
> Active load sharing between supplies
Alcatel 7270 MSC | Release 6.0
