Plastic Door Front Panel Assembly
Illus. No.
Part No.
Qty.
Description
1
881041*
1
Right Hand Front Panel Assembly
(includes illus. nos. 1, 3, 5, and 6)
881043*
1
Left Hand Front Panel Assembly
(includes illus. nos. 1, 3, 5, and 6)
881044
1
Right Hand Stainless Steel Front Panel Assembly
(includes illus. nos. 1, 3, 5, and 6)
2
150309
11
#10-16 x 1/2” Hex Head Crimptite Screw
150313
11
#10-16 x 1/2” TORX Plus BTN Type 1
3
121405
1
Rubber Grommet
4
---------
1
Lint Drawer Switch
(refer to Lint Drawer with Stainless Steel Lint Screen/Lint Drawer
Switch Assembly on page 12)
5
881987
1
Friction Door Latch Kit
(includes illus. nos. 5 and 6)
6
154215
2
5/32” Pop Rivet
*
Specify color when ordering.
