Inputs:
Microphone
1.5mV, 600 Ohm
Phono 3mV, 47kOhm
Line 150mV, 27kOhm
Output 7V, peak to peak
Frequency range 20Hz-20KHz, ± 2dB
Distortion <0.08%
S/N-ratio >70dB
Tone control Treble: 10Khz ± 12dB
Bass: 100 Hz ± 12dB
Headphone impedance 16 Ohms
Power supply DC 12V 500mA
Dimensions 6.5” W x 8.75” D x 3.75” H
211 x 114 x 285 mm
Weight 3.5 lbs. / 1.5 kg
© American DJ® AUDIO Los Angeles, CA 90058 USA
Specifications subject to change without notice. XDM-241 User Instructions page 5
Replacing the Crossfader
Instructions for replacing the crossfader:
• Disconnect from main power supply
• Remove the fader knob.
• Remove the two outer screws.
• Take the fader out and unplug the connection cable.
• Connect the new fader and replace back into mixer.
IMPORTANT! • Only replace cross fader with American DJ® high quality
Feather Fader™ (FF-1).
Technical Specifications - model XDM-241
