Bottom Panel
PIN 1 - OFF PIN 2 – OFF Auto rate detect (143 Mbps rate operation supported only in ARD mode)
PIN 1 - OFF PIN 2 – ON 270 Mbps
PIN 1 – ON PIN 2 – OFF 1483 / 1485 Mbps
PIN 3 - OFF Automatically reclocks bypassed SDI signals
PIN 3 - ON Force to bypass SDI signal
PIN 4 - OFF Default Operation mode
