Electrical Requirements
70269701
56
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
For 24 kW Models:
35 Pound Electric
Table 13
Serial Plate
Voltage
Terminal Block
Connections
Required
Current
(Amps)
Recommended
Fuse or Breaker
Rating (Amps)
Breaker
Poles
Recommended
Minimum
Conductor Size
[AWG (mm
2
)]
208V/60Hz/1ph
L1, L2, Neutral,
and ground
122
175
2
2/0 (67.5)
240V/60Hz/1ph
L1, L2, Neutral,
and ground
107
150
2
1/0 (53.5)
200V/60Hz/1ph
L1, Neutral,
and ground
122
175
1
2/0 (67.5)
200V/50Hz/1ph
L1, Neutral,
and ground
119
150
1
1/0 (53.5)
230-240V/50Hz/
1ph
L1, Neutral,
and ground
108
150
1
1/0 (53.5)
200-208V/60Hz/
3ph
L1, L2, L3,
and ground
71
90*
3
3 (26.7)
200V/50Hz/3ph
L1, L2, L3,
and ground
65
90*
3
3 (26.7)
230-240V/50Hz/
3ph
L1, L2, L3,
and ground
62
80*
3
4 (21.2)
240V/60Hz/3ph
L1, L2, L3,
and ground
62
80*
3
4 (21.2)
380V/50Hz/3ph
L1, L2, L3,
and ground
38
50*
3
6 (13.3)
400-415V/50Hz/
3ph
L1, L2, L3,
and ground
35
45*
3
8 (8.37)
460-480V/60Hz/
3ph
L1, L2, L3,
and ground
31
40*
3
8 (8.37)
*
3 Phase machines should not have fuses, breakers only.
