Additional Procedures 6500—Software Installation Errors and L2 Cache Identification

Identifying L2 Cache DIMM

If the logic board is an OPC, follow these instructions to

positively identify the L2 cache DIMM as compatible or

incompatible:
1 View the back of the cache DIMM.
2 Notice that there is one larger chip and eight smaller

chips. The eight smaller chips are organized in tow

groups of four at each end of the DIMM.

3 Look at the markings on any one of the smaller chips.

They will look similar to this:
IDT 74FST

32384Q (This number is the identifying factor.)

F9637BFU
If this number, not counting the Q or any other letters

present, has five digits, it is compatible with OPC.
