Attribute Name Tag VR Value
Presence
of Value
Source
Step Sequence
> Referenced SOP Class UID (0008, 1150) UI ANAP Auto
> Referenced SOP Instance UID (0008, 1155) UI ANAP Auto
Presentation Intent Type (0008, 0068) CS
For Processing/For
Presentation
ALWAYS Config
Display Shutter
Shutter Shape (0018, 1600) CS ANAP User
Shutter Left Vertical Edge (0018, 1602) IS ANAP User
Shutter Right Vertical Edge (0018, 1604) IS ANAP User
Shutter Upper Horizontal Edge (0018, 1606) IS ANAP User
Shutter Lower Horizontal Edge (0018, 1608) IS ANAP User
Vertices of the Polygonal Shutter (0018, 1620) IS ANAP User
Shutter Presentation Value (0018, 1622) US ANAP User
DX Anatomy
Anatomic Region Sequence (0008,2218) SQ ANAP Config / User
> Anatomic Region Modifier
Sequence
(0008, 2220) SQ ANAP Config
Image Laterality (0020, 0062) CS ALWAYS Config / User
DX Image
Image Type (0008, 0008) CS
ORIGINAL when coming
from a digitizer, DERIVED
when the image comes
from a Save as new
The sub-attribute IOD
Specific Characteristics is
filled in with the exposure
type name for QA images
(used by Auto-QC2)
ALWAYS Auto
Samples per Pixel (0028, 0002) US ALWAYS Auto
Photometric Interpretation (0028, 0004) CS ALWAYS Config
Bits Allocated (0028, 0100) US ALWAYS Auto
Bits Stored (0028, 0101) US ALWAYS Auto
High Bit (0028, 0102) US ALWAYS Auto
Pixel Representation (0028, 0103) US ALWAYS Auto
Pixel Intensity Relationship (0028, 1040) CS ALWAYS Auto
Pixel Intensity Relationship Sign (0028, 1041) SS ALWAYS Auto
Rescale Intercept 13 (0028, 1052) DS 0 and 1 ALWAYS Config
Rescale Slope 28 (0028, 1053) DS 0 and 1 ALWAYS Config
Rescale Type (0028, 1054) LO ALWAYS Config
Presentation LUT Shape (2050, 0020) CS IDENTITY ALWAYS Fixed
Lossy Image Compression (0028, 2110) CS 00 ALWAYS Fixed
Lossy Image Compression Ratio (0028, 2112) DS ANAP Auto
Derivation Description (0008, 2111) ST ANAP Auto
Acquisition Device Processing
Description
(0018, 1400) LO ANAP Auto
Acquisition Device Processing
Code
(0018, 1401) LO ANAP Auto
13
Fixed when using DX for Processing
