1. Engine/Blade Control
2. Wheel Drive Control
3. Adjustable and Folding Handlebars
4. Swivel Wheel Lock (911100) (911101,
330, 525)
5. Grass Bag
6. Rear Door
7. Fuel Tank and Cap
8. Fuel Shutoff Valve (911099, 101, 102)
9. Choke Lever (911099, 101)
10. Height Adjustment Pins (911101, 330,
525)
11. Muffler and Muffler Guard
12. Ignition Switch (911515)
13. Oil Fill/Dipstick
14. Oil Filter (911526)
15. Cutting Height Levers (2 Rear Wheel
Adjusters, 2 Front Wheel Adjusters)
16. Primer Bulb (911330, 331, 514, 515,
525, 526, 531)
17. Air Filter
18. Side Discharge Cover
19. Side Discharge Deflector
20. Mulchmaster™ Plug
21. Handlebar Adjustment Holes
22. Recoil Starter Handle
23. Speed Control Rod
24. Throttle Control (911102, 526)
CONTROLS AND FEATURES
