Fifth
Press and release the valet switch
2 chirps = active locks
Press transmitter Lock button to change
1 chirp = passive locks
or
Sixth
Press and release the valet switch
2 chirps = active arming
Press transmitter Lock button to change
1 chirp = passive arming
or
Seventh
Press and release the valet switch
2 chirps = hardwire
Press transmitter Lock button to change
1 chirp = voltage sense
or
Eighth
Press and release the valet switch
1 chirp = siren and horn output
Press transmitter Lock button to change
2 chirps = siren output only
Press transmitter lock button to change
3 chirps = horn output only
or
Ninth
Press and release the valet switch
2 chirps = horn chirp output 16mS
Press transmitter Lock button to change
3 chirps = horn chirp output 30mS
Press transmitter Lock button to change
1 chirp = horn chirp output 10 mS
or
Tenth
Press and release the valet switch
2 chirps = valet switch override operation
Press transmitter Lock button to change
1 chirp = custom code override operation
or
Eleventh
Press and release the valet switch
2 chirps = chirp delete from transmitter inactive
Press transmitter Lock button to change
1 chirp = chirp delete from transmitter active
Press and release the valet switch
Exit program mode
or
Turn ignition key off
Exit program mode
Note: Once you enter the feature programming mode, do not allow more than 15 seconds to pass between steps, or
the programming will be terminated.
INSTALLATION OF MAJOR COMPONENTS
Control Module:
Select a mounting location inside the passenger compartment (up behind the dash), and secure using the
two screws provided. The control module can also be secured in place using cable ties.
Do not mount the control module in the engine compartment, as it is not waterproof. You should also avoid
mounting the unit directly onto factory installed electronic components. These components may cause RF
interference, which can result in poor transmitter range or intermittent operation.
Siren:
Select a mounting location in the engine compartment that is well protected from access below the
vehicle. Avoid areas near high heat components or moving parts within the engine compartment. To
prevent water retention, the flared end of the siren must be pointed downward when mounted.
Mount the siren to the selected location using the screws and bracket provided.
Hood or Trunk Pin Switch:
A pin switch is included for use in protecting the hood or trunk (or hatchback) of the vehicle. The switch
must always be mounted to a grounded, metal surface of the vehicle. It is important to select a location
where water cannot flow or collect, and to avoid all drip gutters on hood and trunk fender walls. Choose
locations that are protected by rubber gaskets when the hood or trunk lid is closed.
The pin switch can be mounted using the bracket provided, or direct mounted by drilling a ¼" diameter
mounting hole. Keep in mind that when properly mounted, the plunger of the pin switch should depress at
least ¼ " when the hood or trunk lid is closed.
Dash Mounted LED:
A small red LED is included that will serve as a visual indicator of the alarm status. It should be installed in
