INTERFACES
9
position of the image can be adjusted through
the Horizontal Position Control knob located on
the front panel. Similarly, one can only adjust the
position of the image on the display for Input 2
using the Horizontal position control knob when
the CH2 Horizontal Delay switch is in the OFF
position.
7.3 I.D. BIT SWITCH 1& 2
Many computers use ID Bits or “Sense Pins” to
recognize that a monitor has been connected to
its video output port. Often, these ID Bits will
allow the computer to recognize what type of
monitor is connected in terms of its scan rate
compatibility. When the ID Bit switch is in the
ON position, the VA6831FC allows the main ID
Bit (pin 4 on the input connector) to be
connected to the Ground signal.
This is used primarily when interfacing laptop
computers to imitate the presence of a local
monitor. Typically, this recognition will take place
during the boot up stage. If your Interface does
not output video on the display, then place this
switch in the ON position and reboot the
computer. When left in the OFF position, this ID
Bit will be passed through to the local monitor
output port.
ACCESSORIES 8
Model No. Description
RACK MOUNT ACCESSORIES
DA1293SX Rack/Wall Shelf fits two VA6831FC
units side by side
DA1294SX Rack/Wall mount ears for single
VA6831FC
TABLE MOUNT BRACKETS
TM1271 1U High, ½ Rack-Wide
TM1272 1U High, ½ Rack-Wide with 15-pin
HD connector plate
TM1273 1U High, ½ Rack-Wide with snap-in
connectors
TM1274 1U High, ½ Rack-Wide with snap-in &
POWER connectors
Input cable Local Monitor Cables and Output
Cables must be ordered separately from following
list.
Model No. Description
INPUT/LOCAL MONITOR CABLES
MS8121CA MAC Local Monitor Cable
MS8122CA MAC Input Cable
MS8123CA SUN/SGI Local Monitor Cable
MS8124CA SUN/SGI Input Cable
MS8125CA VGA Local Monitor Cable
MS8126CA VGA Input Cable
MS8129CA 5 BNC Input/Local Monitor Cable
4 BNC TO 4 BNC COAXIAL CABLE
CB4103MR 3 feet, 4 BNC to 4 BNC coaxial cable
CB4106MR 6 feet, 4 BNC to 4 BNC coaxial cable
CB4112MR 12 feet, 4 BNC to 4 BNC coaxial
cable
CB4125MR 25 feet, 4 BNC to 4 BNC coaxial
cable
CB4150MR 50 feet, 4 BNC to 4 BNC coaxial
cable
CB4175MR 75 feet, 4 BNC to 4 BNC coaxial
cable
CB41100MR 100 feet, 4 BNC to 4 BNC coaxial
cable
CB41150MR 150 feet, 4 BNC to 4 BNC coaxial
cable
5 BNC TO 5 BNC COAXIAL CABLE
CB4203MR 3 feet, 5 BNC to 5 BNC coaxial cable
CB4206MR 6 feet, 5 BNC to 5 BNC coaxial cable
CB4212MR 12 feet, 5 BNC to 5 BNC coaxial
cable
CB4225MR 25 feet, 5 BNC to 5 BNC coaxial
cable
CB4250MR 50 feet, 5 BNC to 5 BNC coaxial
cable
CB4275MR 75 feet, 5 BNC to 5 BNC coaxial
cable
CB42100MR 100 feet, 5 BNC to 5 BNC coaxial
cable
CB42150MR 150 feet, 5 BNC to 5 BNC coaxial
cable
All MS81 Series cables listed above are 3 ft. long.
These cables are available in 6 ft. and 12 ft.
lengths. Please call 1-714-990-2300 for a wider
selection of cables.
