Getting Started
10
Ge
tting S
tar
ted
1
Mounting the main
unit on a wall
You can mount the main unit on a wall.
Prepare screws and brackets.
Unit
Wall mount bracket
Wall Mount Bracket
Installation Template
1. Match the TV’s BOTTOM EDGE of Wall Mount
Bracket Installation Template with the bottom
of TV and attach to the position.
TV
2. When you mount it on a wall (concrete), use the
wall plugs (Not supplied). You should drill holes.
A guide sheet (Wall Mount Bracket Installation
Template) is supplied to drill. Use the sheet to
check the point to drill.
Wall Mount Bracket Installa
tion Template
Screws and Wall Plugs are not supplied for
mounting the unit. We recommend the Hilti
(HUD-1 6 x 30) for the mounting.
,
Note
NB2030A-N0.DUSALLK.130108.indd 10
2013-01-10 11:59:45
