LG 55UB8500 - Manual (Page 37)

37
ENGLISH
SPECIFICATIONS
MODELS
55UB9500
(55UB9500-UA)
65UB9500
(65UB9500-UA)
Dimensions
(W x H x D)
With stand
1,232 x 782 x 260 (mm) 1,452 x 914 x 300 (mm)
48.5 x 30.7 x 10.2 (inch) 57.1 x 35.9 x 11.8 (inch)
Without stand
1,232 x 734 x 37 (mm) 1,452 x 858 x 37 (mm)
48.5 x 28.8 x 1.4 (inch) 57.1 x 33.7 x 1.4 (inch)
Weight
With stand 23.8 kg (52.4 lbs) 34.8 kg (76.7 lbs)
Without stand 23.1 kg (50.9 lbs) 33.7 kg (74.2 lbs)
Current Value / Power consumption 2.1 A / 210 W 2.3 A / 230 W
Power requirement AC 100 - 240 V ~ 50 / 60 Hz AC 120 V~ 50 / 60 Hz
MODELS
65UC9700
(65UC9700-UA)
Dimensions
(W x H x D)
With stand
1,391 x 881 x 340 (mm)
54.7 x 34.6 x 13.3 (inch)
Without stand
1,391 x 824 x 56.0 (mm)
54.7 x 32.4 x 2.2 (inch)
Weight
With stand 35.7 kg (78.7 lbs)
Without stand 33.0 kg (72.7 lbs)
Current Value / Power consumption 2.5 A / 250 W
Power requirement AC 120 V~ 50 / 60 Hz
Wireless module (LGSBW41) Specifications
Wireless LAN Bluetooth
Standard IEEE 802.11a/b/g/n Standard Bluetooth Version 3.0
Frequency range
2400 to 2483.5 MHz
5150 to 5250 MHz
5725 to 5850 MHz
Frequency range 2400 to 2483.5MHz
Output power(Max.)
802.11a: 11.5 dBm
802.11b: 11 dBm
802.11g: 10.5 dBm
802.11n - 2.4GHz: 11 dBm
802.11n - 5GHz: 12.5 dBm
Output power(Max.) 10dBm or Lower
• Because band channel used by the country could be different, the user can not change or adjust the operating
frequency and this product is set for the regional frequency table.
• This device should be installed and operated with minimum distance 20 cm (7.8 inch) between the device and your
body. And this phrase is for the general statement for consideration of user environment.
• Contains FCC ID: BEJLGSBW41 / Contains IC: 2703H-LGSBW41
