OUTDOOR DRAINAGE
CAUTION
23
I N S T A L L A T I O N I N S T R U C T I O N S
2. Install end point of the drain pipe to the unit, connect the other end pipe to the drain hole of the window panel.
1.Remove the water plug firstly.
When water is being drained at the drain pipe, you can press TIMER and DOWN buttons simultaneously to stop
the drain pump inside when unit is run, or press TIMER and DOWN buttons simultaneously again to turn on the
drain pump.
HEATING DRAINAGE
Rotate the nut cover on the vent panel. 1
2 Insert drain pipe into the vent panel
3 When installing the drain pipe on the vent panel, keep end pipe of outdoor far away from install kit more than 8”.
4 Rotate nut cover to fix the drain pipe.
English
Push Here
before Rotation
More than 8”
