A5
Connecting the Display
Before setting up the monitor, ensure that the power to the monitor, the computer
system, and other attached devices is turned off.
Positioning your display
1
. Adjust the position of the panel in various ways for maximum comfort.
Tilt Range : -3˚~17˚ Swivel :356˚
Ergonomic
It is recommended that in order to maintain an ergonomic and comfortable viewing position, the forward
tilt angle of the monitor should not exceed 5 degrees.
You do not need to replace the Locking pin after it is removed, to adjust its height.
Height Range : maximum 5 .51 inch (140.0mm)
140.0mm
* Please be sure to
remove the Locking
pin to adjust the height.
