Care and Maintenance
30
How to remove and replace parts
Freezer
compartment
lamp
Freezer
compartment
shelf
Door rack and
support
Ice storage bin
After dispenser
is used
To remove a shelf, push the shelf to the left ,
lift the left part of the shelf a bit , lift the right
part up
➂ , and take it out.
Lift the door rack holding both sides and
pull it out .
The water collector has no self-drainage
function, so it should be cleaned regularly.
Remove the cover by pulling the front of the
water collector cover and dry it with a cloth.
Hold the ice storage bin as shown in the right
figure and pull it out
while slightly lifting it .
Do not dismantle the ice storage bin unless
it is necessary.
Use both hands to remove the ice bin to avoid
dropping it.
!
!
• Dismantling is done in the reverse sequence of assembly.
Be sure to unplug the power plug before dismantling and assembly.
Never apply severe force to dismantle parts. Parts may be damaged.
• The light bulbs will turn off if door is left open for seven continuous minutes.
Shutting door for one second will light bulbs to come back on.
NOTE
Separate the lamp by pulling it out
➂ while
slightly striking
➀ and rotating ➁ the lamp cover.
Turn the bulb counterclockwise. Max. 40 W bulb
for refrigerator is used and can be purchased at
a service center.
Insert the tool into the marked area ( ) and push
the tool to disconnect.
Use the tool with the flat tip such as a flat (-) screw
driver.
Turn the bulb counterclockwise. Max. 40 W bulb
for refrigerator is used and can be purchased at a
service center. Lamp in
refrigerator
compartment
