Some specifications above may change with with out notice. Contact Amcor for updates and review installation materials prior to installation.
Amcor Inc. 685A Gotham Parkway, Carlstadt, NJ 07072 www.amcorgroupusa.com
Indoor Model # AWM093HX * 2 AWM093HX + AWM123HX AWM123HX * 2
Outdoor Model # AOM183HX AOM243HX AOM243HX
Capacity (BTU)
Cooling
18,000(9,550-23,900) 21,000 (10,200—29,000) 24,000 (10,200—29,000)
Heating 22,000 (9,500—23,900)
23,500 (9,500—27,300) 25,000(9,500—27,300)
SEER
14.0 14.0 14.0
HSPF
7.8 7.8 7.8
Op Range Cool 5 0—131 50—131 50—131
Op Range Heat - 4— 89 - 4— 89 - 4— 89
Dehumidification (Pts/hr) 1.55 1.55 / 2.11 2.11
Voltage
230/208-60-1 230/208-60-1 230/208-60-1
Input Current (A) Rated /Max Cooling
6.0 / 10.5 8.0 / 13.0 8.0 / 13.0
Heating
6.7 / 9.8 8.7 / 12.5 8.7 / 12.5
Power Use (KW) Rated / Max Cooling
1.38 / 2.43 1.83 / 2.93 1.83 / 2.93
Heating
1.55 / 2.35 2.0 / 2.45 2.0 / 2.45
Max Overload Protection (A)
20 25 25
Indoor Air Circulation CFM L-M-H
190 / 306 / 353 190 / 306 / 353(218 / 406 / 459) 218 / 406 / 459
Indoor Noise level dB(A) L-M-H
35 / 38 / 42 35 / 38 / 42 35 / 38 / 42
Indoor Fan Speeds(RPM) L-M-H
750 / 950 / 1150 750 / 950 / 1150(750 / 950 / 1200) 750 / 950 / 1200
Fan Speeds 3 + Auto 3 + Auto 3 + Auto
Outdoor Noise Level dB(A)
57 57 57
Outdoor Fan Speed (RPM)
500/750/900 500/750/900 500/750/900
Connection Method
Flare Flare Flare
Max Pipe Length (Ft.)
82 82 82
Max Elevation (Ft.)
33 33 33
Pipe Size (In.)
1/4—3/8 1/4—3/8 &1/4—1/2 1/4—1/2
Service Port Connection (In.) 5/16 5/16 5/16
Indoor Dimensions W x H x D
31-
1/8 x 10- 5/8 x 8- 1/4
31-1/8 x 10-5/8 x 8-1/4(36-5/8 x 10-7/8 x 8-1/4) 36-
5/8 x 10- 7/8 x 8- 1/4
Net Weight (lbs.)
26 26(31) 31
Outdoor Dimensions
36-
1/2 x 27- 5/8 x 14- 1/4
35 -3/8 x 32-1/8 x 13 35-
3/8 x 32- 1/8 x 13
Net Weight (lbs.)
123 143 143
Refrigerant R-410A R-410A R-410A
