BACK PANEL INFORMATION
PREP
AR
A
T
ION
10
PREPARATION
AV IN 2
L/M
O
N
O
R
AUDIO
VIDEO
USB IN
/ DVI IN 3
R
7
1
11
ANTENNA/
CABLE IN
2
1
RGB IN (PC)
(CONTROL
& SER
VICE)
OPTICAL
DIGITAL
AUDIO OUT COMPONENT IN
1
2
VIDEO AUDIO
A
V
IN 1
/DVI IN
AUDIO IN
(RGB/DVI)
REMOTE
CONTROL IN
AUDIO VIDEO (MONO) S-VIDEO
R
RS-232C IN
1 2
4 9 7
6
8
5
3
10
60PS11
42/50PQ10, 42/50PQ12, 50PS11
ANTENNA/
CABLE IN
2
1
RS-232C IN
(SER
VICE ONL
Y)
OPTICAL
DIGITAL
AUDIO OUT
COMPONENT IN
1
2
VIDEO AUDIO
L R
AUDIO
A
V
IN
VIDEO (MONO)
IN
USB SER
VICE ONL
Y
1 2
4 5 7
6
8
HDMI IN, HDMI/DVI IN
Digital Connection. Supports HD video and Digital
audio. Doesn’t support 480i.
Accepts DVI video using an adapter or HDMI to
DVI cable (not included).
OPTICAL DIGITAL AUDIO OUT
Optical digital audio output for use with amps and
home theater systems.
Note: In standby mode, this port doesn’t work.
AUDIO IN (RGB/DVI) (For 60PS11)
1/8" (0.32 cm) headphone jack for analog PC audio input.
RS-232C IN (CONTROL & SERVICE) PORT
(For 60PS11)
Used by third party devices.
USB IN (For 60PS11)
Used for viewing photos and listening to MP3s.
USB SERVICE ONLY
(Except 60PS11)
Used for software updates.
COMPONENT IN
Analog Connection. Supports HD.
Uses a red, green, and blue cable for video & red
and white for audio.
AV (Audio/Video) IN
Analog composite connection. Supports standard
definition video only (480i).
S-VIDEO (For 60PS11)
Better quality than standard composition.
Supports standard definition video only (480i).
ANTENNA/CABLE IN
Connect over-the air signals to this jack.
Connect cable signals to this jack.
RGB IN (PC) (For 60PS11)
Analog PC Connection. Uses a D-sub 15 pin cable
(VGA cable).
REMOTE CONTROL IN (For 60PS11)
For a wired remote control.
Power Cord Socket
For operation with AC power.
Caution: Never attempt to operate the TV on DC power.
