Composite Connection
Transmits analog video and audio signals from an external device to the TV. Connect the external device
and the TV with a composite cable as shown in the following illustration.
NOTE
y
y
If you have a mono VCR, connect the audio cable from the VCR to the AUDIO L/MONO jack of the TV.
