EXTERNAL
EQ
UIPMENT
SETUP
17
HDMI Connection
Connect the digital set-top box to H HD DM MII//D DV VII IIN N1 1,
2 2, or H HD DM MII IIN N3 3 jack on the TV.
No separate audio connection is necessary.
HDMI supports both audio and video.
1. How to connect
2. How to use
■ Turn on the digital set-top box.
(Refer to the owner’s manual for the digital set-top box.)
■ Select the H HD DM MII1 1 , H HD DM MII2 2 , or H HD DM MII3 3 input source on the
TV using the IIN NPPU UT T button on the remote control.
2
1
HDMI-DTV
Horizontal Vertical
Frequency(KHz) Frequency(Hz)
31.469 59.94
31.50 60.00
44.96 59.94
45.00 60.00
33.72 59.94
33.75 60.00
27.00 24.00
33.75 30.00
67.43 59.94
67.50 60.00
Resolution
720x480p
1280x720p
1920x1080i
1920x1080p
RGB IN
OMPONENT IN
AUDIO
(RGB/DVI)
RGB(PC)
HDMI/DVI IN
2
1
EO
L B P R R
AUDIO
HDMI-DTV OUTPUT
( ) ( )
( )
1
