14 Room Air Conditioner
Installation
1. Do not pull the window sash down so tightly
that the movement of frame curtain is
restricted. Attach the cabinet to the window
stool by driving the screws (Type B) through
the cabinet into window stool.
2. The cabinet should be installed with a very
slight tilt downward toward the outside.
NOTICE
Screw(Type B)
Front Angle
Sash track
Pull each frame curtain fully to each window sash
track, and pull the bottom window sash down behind
the t op retainer bar until it meets.
Power Cord
Screw (Type A)
Screw
Window locking
bracket
Foam-Strip
（ Not adhesive backed）
3.
Attach each frame curtain the window sash by
using screws (Type C). 4.
5. Slide the unit into the cabinet.
For security purpose, reinstall screws
（removed from cabinet）at cabinet's sides.
See page 13.
6.
7.
Cut the foam-strip （ Not adhesive backed
to the proper length and insert between the
upper window sash and the lower window sash.
Attach the Window locking bracket with a screw
(Type C).
