ENGLISH
27 MAKING CONNECTIONS
Connecting Headphones
You listen to the sound using headphones.
y y AUDIO menu options are disabled when connecting a headphone.
y y When changing AV MODE with a headphone connected, the change is applied to video but not to audio.
y y Optical Digital Audio Out is not available when connecting a headphone.
y y Headphone impedance: 16 Ω
y y Max audio output: 10 mW to 15 mW
y y Headphone jack size: 0.35 cm (0.13 inches)
NOTE
OPTICAL
DIGITAL
AUDIO
OUT
H/P
Headphone
(*Not Provided)
Connecting a USB Device
Connect a USB storage device such as a USB flash memory, external hard drive, or a USB memory card reader
to the TV.
y y Some USB Hubs may not work. If a USB device connected using a USB Hub is not detected, connect it to the
USB port on the TV directly.
NOTE
1
2
3
USB IN
USB
USB Hub
(*Not Provided)
Choose any USB input port to connect.
It does not matter which port you use.
