ASSEMBLING AND PREPARING
Jack
Description
1
Power Cord Socket
For operation with AC power.
Caution: Never attempt to operate the TV on DC power.
2
ANTENNA IN
Connect over-the air signals to this jack.
3
PTC SERVICE
(SERVICE ONLY)
Used for PTC software updates.
4
CPU SERVICE
(SERVICE ONLY)
Used for CPU software updates.
5
TV - LINK CFG
Computer input for programming Free To Guest services.
6
SPEAKER OUT 8
Ω
For use with external speakers.
7
GAME CONTROL
Input port for third party game Controllers.
M. P. I.
Allows VOD/PPV devices or set-top boxes to control the TV.
8
PILLOW SPEAKER
Used to connect to pillow speaker.
9
AUDIO IN (RGB/DVI)
1/8” headphone jack for analog PC audio input.
-
USB IN
Used for viewing multimedia files.
q
RGB IN (PC)
Analog PC Connection. Uses a D-sub 15-pin cable (VGA cable).
w
HDMI/DVI IN
Digital Connection.
Supports HD video and Digital audio.
Accepts DVI video using an adapter or HDMI to DVI cable (not included).
e
AV (Audio/Video) IN
Analog composite connection. Supports standard definition video only (480i).
Used for PC/DTV audio input jack.
r
UPDATE
Software downloads and debug mode enable/ dis-able.
RESET
Hardware reset to PTC microcontroller.
?
RS-232C IN
(SERVICE ONLY)
Used for software updates.
