ENGLISH
TO REMOVE THE DOOR
w
WARNING
THEDRYERDOORISVERYLARGEANDHEAVY.Failure to follow the instructions below can result in damage
to the dryer, property damage or injury to persons .
• To avoid damage to the dryer or the door, support the door with a stool or box that fits under the door, or have
an assistant support the weight of the door.
• Always reverse the door BEFORE stacking the dryer on top of the washer.
• Avoid dropping the door to avoid damage to the door or the floor.
Remove four dummy screws by driver. 3
Hinge
Dummy
Screw
Remove door from cabinet cover. 6
Remove
Door
Check screws to remove (Left 6, Right 4). 2 Hold on the hinge while remove 4 screws of
hinge (to prevent door dropping).
5
Hinge Screw
Open the door to reverse. 1
Open Door
Remove two screws and disassembly Latch. 4
Latch Screw
13
