12
DOOR AND DRAWER REMOVAL
(CONT.)
DOOR REINSTALLATION
Install the right-side door first.
• Lower the door onto the middle hinge pin as
shown.
1 • Fit the top hinge (1) over the hinge lever
latch (2) and into place. Insert the hinge
lever (3) under the lever latch. Rotate the
lever counterclockwise to secure the hinge.
• Connect the wire harness (4).
• Hook the tab on the door-switch side of the
cover (5) under the edge of the wire opening
in the cabinet top. Position the cover into
place. Insert and tighten the cover screw (6).
(3)
(2)
(1)
(6)
(5)
(4)
2
Install the left-side door.
• Lower the door onto middle hinge pin.
3 • Fit the top hinge (1) over the hinge lever
latch (2) and into place. Insert the hinge
lever (3) under the lever latch. Rotate the
lever clockwise to secure the hinge.
• Install the grounding screw (4) and connect
all the wire harnesses (5).
(2)
(1)
(3)
(4)
(5)
4
