REFRIGERATOR INSTALLATION
16
2. Replacing Refrigerator Door
❿ Right Door
• Lower the door onto the middle hinge pin (6).
• Make sure the door is aligned with the
cabinet.
• Replace the top hinge (5) by rotating the lever
hinge (4) counter clockwise to secure it.
• Make sure the gasket on the door is flush
against the cabinet and is not folded.
• Support the door on the handle side while
securing. And make sure the door is straight
and the gap between the doors is even
across the front.
• Install the ground screw (3) and connect the
wire harness (2).
• Tighten the cover screw (1).
❿ Left Door
• Replace the left door followed by the same
way described above.
• When replacing the top hinge (5), rotate the
lever hinge (4) clockwise at this time.
: Be careful of missing the
washer [part(7)]. Because it can be easily
taken off.
6
6
7
7
CAUTION
