P OWER O UTPUT
The EA-380D Green PSU distributes a varying maximum number of amps on each rail. To see the output
capacity and regulation for each different voltage, see Table 3.
T ABLE 3: O UTPUT C APACITY AND R EGULATION
Output
Voltage
Load Max. Regulation Ripple & Noise
+3.3V 20A ±5% 50 mV
+5V 20A ±5% 50 mV
+12V1 17A ±5% 120 mV
+12V2 15A ±5% 120 mV
–12V 0.8A ±10% 120 mV
+5VSB 2.5A ±5% 50 mV
The continuous maximum total output power shall not exceed 380W.
+12V1 and +12V2 DC maximum output power shall not exceed 336W.
+3.3V and +5V DC maximum combined output power shall not exceed 115W
I
NSTALLATION
:
1. Install the EA-380D Green PSU into your case with the four screws provided.
2. Connect the 24-pin main power connector to your motherboard. If your motherboard uses a 20-
pin connector, detach the 4-pin attachment on the 24-pin connector.
Note: The detachable 4-pin section cannot be used in place of a 4-pin +12V connector.
