DVD SETUP
Component Connection
Component Input ports
To get better picture quality, connect a DVD player to the component input ports as shown below.
Component ports on the TV Y P B P R
Video output ports
on DVD player
Y
Y
Y
Y
P B
B-Y
Cb
Pb
P
R
R-Y
Cr
Pr
Connect the video outputs (Y, P B , P R
) of the DVD to the
C CO OM MPPO ON NEEN NT T IIN N V VIID DEEO O jacks on the TV. Match the
jack colors (Y = green, P B = blue, and P R = red).
Connect the audio outputs of the DVD to the C CO OM MPPO O--
N NEEN NT T IIN N A AU UD DIIO O jacks on the TV.
1. How to connect
2. How to use
■ Turn on the DVD player, insert a DVD.
■ Select C Co om mp po onneenntt input source by using the IIN NPPU UT T
button on the remote control.
■ Refer to the DVD player's manual for operating instructions.
