ASSEMBLING AND PREPARING
Parts and buttons
Touch button
2
Description
/ I
Turns the power on or off.
INPUT
Changes the input source.
HOME
Accesses the main menus, or saves your input and exits the menus.
ENTER
⊙
Selects the highlighted menu option or confirms an input.
- VOL +
Adjusts the volume level.
v CH ^
Scrolls through the saved channels.
1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.
2 All of the buttons are touch sensitive and can be operated through simple touch with your finger.
AV IN 2
L/
MO
NO
R
AUDI
O
VIDE
O
USB IN
IN
3
ENTER
CH
VOL
HOME
INPUT
ANTENNA
/CABLE
IN
RS-232C IN
(CONTROL & SERVICE)
RGB IN (PC)
AUDIO IN
(RGB/DVI)
OPTICAL
DIGITAL
AUDIO OUT
/DVI IN
2
1
2
1
VIDEO
AUDIO
L(MONO)
R
VIDEO
AUDIO
COMPONENT IN
AV IN 1
Y
P
B
P
R
R
L
REMOTE
CONTROL IN
USB input
HDMI input
AV (Audio and
Video) input
Screen
Speakers
Rear Connection
Touch buttons
2
Side Connection panel
Remote control and
intelligent
1
sensors
