Bottom view

I

TEM

L

ABEL

D

ESCRIPTION

S

EE PAGE

:

31

1.

Lamp cover

Remove when changing the lamp.

2.

Lens cap hook

To fasten the lens cap cover.

3.

Tilt adjustor

Rotate adjuster lever to adjust angle position.

– 5 –

4.

Height adjustor button

Push to release adjustor.

15

5.

Height adjustor

Adjuster drops down when adjuster button is pushed.
