Connections
Composite Connection
Transmits the analog video and audio signals from an external device to the TV. Connect the external
device and the TV with the composite cable as shown in the following illustration.
IN
COMPONENT
AV
VIDEO AUDIO
Y
P
B
P
R
VIDEO
AUDIO
VCR / DVD/ Blu-Ray / HD Cable Box
(*Not Provided)
YELL
O
W
WHITE
RED
YEL
LO
W
WHITE
RED
YELL
O
W
YELLOW
WHITE
RED
(Use the composite video cable provided.)
