LG 47LH30 - Manual (Page 34)

EXTERNAL
EQ
UIPMENT
SETUP
34
EXTERNAL EQUIPMENT SETUP
DVI to HDMI Connection
RS-232C IN
(CONTROL&SERVICE)
ANTENNA/
CABLE IN
AUDIO
RGB IN (PC) EO AUDIO
L(MONO) R
AV IN
NT IN
L R
AUDIO IN
(RGB/DVI) OPTICAL DIGITA
AUDIO OUT
L R DVI OUTPUT
AUDIO
2
1
/DVI IN
1
2
G G A DVI to HDMI cable or adapter is required for this con-
nection. DVI doesn't support audio, so a separate audio
connection is necessary.
NOTE !
Connect the DVI output of the digital set-top box to
the H
HD DM MII//D DV VII IIN N or H HD DM MII//D DV VII IIN N 1 1//2 2* jack on
the TV.
Connect the digital set-top box audio output to the
A
AU UD DIIO O IIN N ((R RG GB B//D DV VII)) jack on the TV.
1. How to connect
2. How to use
■ Turn on the digital set-top box.
(Refer to the owner’s manual for the digital set-top box.)
■ Select the H HD DM MII or H HD DM MII1 1//2 2 * input source on the TV
using the IIN NPPU UT T button on the remote control.
2
1
* HDMI 2: Except 19/22LH20, 22LH200C
