MAKING CONNECTIONS
Component connection
Transmits analog video and audio signals from an external device to the TV. Connect the external
device and the TV with a component cable as shown in the following illustration.
•
If cables are installed incorrectly, it could cause the image to display in black and white or with
distorted color.
•
Check to ensure the cables are matched with the corresponding color connection.
NOTE
VIDEO
AUDIO
L
R
Y
P
R
P
B
GREEN
GREEN
GREEN
GREEN
(Use the component video cable provided.)
BL
UE
BL
UE
BL
UE
RED
RED
RED
YELL
O
W
YELLOW
(Use the composite video cable provided.)
WHITE
WHITE
WHITE
RED
RED
RED
Blu-Ray / HD Cable Box / DVD
(*Not provided)
(*Not provided)
