Enter Starter Program Mode - See Page 7 for details on entering program mode
PROGRAM MODE - TACH SETTINGS
Setting 1- Method 2- Low Idle Tach Learning
Setting 2- Adjust For Over-Crank
Setting 3- Adjust For Under-Crank
Step 1 - Enter Program Mode (Ignition ON-OFF-ON-OFF-ON) then press the Program Button on the antenna 1 time.
Step 2 - Enter Program Menu 4 - Press
Button #4 on the remote.
Step 3 - Start Vehicle - Using the ignition key, make sure not to turn the key off at any time or your will exit programming.
Step 4 - Press the Program Button - One time (LED- flashing in single cycles) then press and hold button for (5sec).
Step 5 - Release Program - Led should come on steady to indicate correct tach signal the park light will flash to confirm.
Step 1 - Enter Program Mode (Ignition ON-OFF-ON-OFF-ON) then press the Program button on the antenna 1 time.
Step 2 - Enter Program Menu 4 - Press
Button #4 on the remote.
Step 3 - Press the Program Button -
2 times (Led will start flashing 2 times).
Step 4 - Press and Hold Program - For 5 seconds until parking lights flash (each time lights flash tach is reduced).
Step 5 - Release Program - Exit Program Mode and remote start to test.
Step 1 - Enter Program Mode (Ignition ON-OFF-ON-OFF-ON) then press the Program button on the antenna 1 time.
Step 2 - Enter Program Menu 4 - Press Button #4 on the remote..
Step 3 - Press the Program Button -
3 times (Led will start flashing 3 times).
Step 4 - Press and Hold Program - For 5 seconds until parking lights flash (each time lights flash tach is increased).
Step 5 - Release Program - Exit Program Mode then remote start to test.
11
This option is used for vehicles that maintain a HIGH or erratic idle after starting and need more that 10
seconds to establish a stable idle.
Setting 1 - Method 1- Auto Tach Learning. See page 7.
1 Type `1 1 Flash Unlock pulse before start, lock pulse after start and after shutdown
2 Type 2 2 Flashes Lock pulse after remote starter shuts off
3* Normal Operation 3 Flashes No additional re-lock pulses
1 Negative Glow Plug 1 Flash Waits a Maximum of 30 second before starting.
2 Timed Delay 2 Flashes Ignition ON for 10 seconds before engaging remote starter
3* Gas/ Glow Plug (+) 3 Flashes If no diesel input is detected the vehicle will start after two seconds.
1 Type 1 1 Flash Pulse after start and with lock
2 Type 2 2 Flashes Pulse after start only
3* Factory Re-arm 3 Flashes 0.75 second pulse with lock and after shutdown
Setting 1- Special Door Lock/ Unlock Operations
Setting 2- Gas/ Diesel Mode- Blue Wire on 14-Pin
Setting 3- Rearm Output- Yellow Wire on 14-Pin
1 30 Min Run Time 1 Flash Remote Starter runs for 30min when activated
2 45 Min Run Time 2 Flashes Remote Starter runs for 45min when activated
3* 15 Min Run Time 3 Flashes Remote Starter runs for 15 min when activated
1 10 Seconds 1 Flash 10 sec Max time that starter will stay engaged
2 3 Seconds 2 Flashes 3 sec Max time that starter will stay engaged
3* 5 seconds 3 Flashes 5 sec Max time that starter will stay engaged
Setting 4- Run Time
Setting 5-Maximum Crank Time
Setting 6- Starter Kill / Aux. Horn - Orange wire on 14-Pin Con.
1 Horn Output 1 Flash Pulsed output to activate negative horn.
2* Starter Disable 2 Flashes Negative output while the system is armed
1 Safety ON 1 Flash Must press the start button twice to remote start vehicle
2* Safety OFF 2 Flashes Press the start button once to remote start vehicle.
Setting 8- Safety Start Mode
Setting 7- Sensor Disconnect - Blue wire on 3-Pin Con.
1 Positive Start Input 1 Flash Positive pulse will activate remote starter.
2 Positive Disconnect 2 Flashes Alarm will trigger if disconnected from 12 volts.
3* Positive Disconnect 3 Flashes Alarm will trigger if disconnected from 12 volts.
Continued on next page...
Press the Program Button 1 time to select setting 1 (This will be confirmed by 1 LED flash)
Press and hold the Program Button until you receive the appropriate # of park light flashes and siren chirps.
Release the Program Button. Press momentarily to move to next program step or repeat to change selection.
Press the Program Button 2 times to select setting 2 (This will be confirmed by 2 LED flashes)
Press and hold the Program Button until you receive the appropriate # of park light flashes and siren chirps.
Release the Program Button. Press momentarily to move to next program step or repeat to change selection.
Press the Program Button 3 times to select setting 3 (This will be confirmed by 3 LED flashes)
Press and hold the Program Button until you receive the appropriate # of park light flashes and siren chirps.
Release the Program Button. Press momentarily to move to next program step or repeat to change selection.
Press the Program Button 4 times to select setting 4 (This will be confirmed by 4 LED flashes)
Press and hold the Program Button until you receive the appropriate # of park light flashes and siren chirps.
Release the Program Button. Press momentarily to move to next program step or repeat to change selection.
Press the Program Button 5 times to select setting 5 (This will be confirmed by 5 LED flashes)
Press and hold the Program Button until you receive the appropriate # of park light flashes and siren chirps.
Release the Program Button. Press momentarily to move to next program step or repeat to change selection.
Press the Program Button 6 times to select setting 6 (This will be confirmed by 6 LED flashes)
Press and hold the Program Button until you receive the appropriate # of park light flashes and siren chirps.
Release the Program Button. Press momentarily to move to next program step or repeat to change selection.
Press the Program Button 7 times to select setting 7 (This will be confirmed by 7 LED flashes)
Press and hold the Program Button until you receive the appropriate # of park light flashes and siren chirps.
Release the Program Button. Press momentarily to move to next program step or repeat to change selection.
Press the Program Button 8 times to select setting 8 (This will be confirmed by 8 LED flashes)
Press and hold the Program Button until you receive the appropriate # of park light flashes and siren chirps.
Release the Program Button. Press momentarily to move to next program step or repeat to change selection.
Step 1 - Within three seconds turn the ignition Key ON-OFF-ON-OFF-ON - Leaving Key ON
Step 2 - Press and hold the Program Button - Parking Lights will come ON
**if the park-lights do not come on at this point, turn the key off for 5 seconds, the repeat step 1.
Step 3 - Continue to hold the Program Button the park lights will go out. (Do not release program switch)
Step 4 - The siren will chirp five time quickly, Press button 1 on the remote transmitter (ensure the
“#” symbol is not displayed on the LCD) the park light will flash to confirm transmitter programming.
