Assembly
BM 5001-R
(B&S)
Fill the mower with engine oil and
petrol only after it has been
completely assembled!
Pull off the spark plug connector
before starting the assembly!
i
The number printed on the left before
the text (e.g.
3
) refers to the diagrams.
.
1
. .
2
. Loosen screws and rotate handlebar
console upwards – retighten screws.
Assembly of handlebars on console
.
3
. Handlebars
.
4
. Mount handlebars on console.
Hexagonal screw M8 x 25 - (2x)
Hexagonal nut
M8 self-locking - (2x)
Bowden cable guide - (1x)
.
5
. The handlebars can be set to the user's
height by attaching them to the lower or
upper position.
.
6
. Mount the Bowden cable guide together
with the lower screw - tighten the nuts.
Assembly of blade holder
.
7
. Blade holder
.
8
. Mounting
bush
on
the
housing
to
accommodate the blade holder.
.
9
. Lightly grease the mounting bush and insert
the blade holder.
10
. Fully insert the blade holder and place the
V belt around the pulley.
Place the V belt around the lower pulley
in the housing.
Assembly of recoil springs
11
.
12
.
y Place the mower on its side.
y Hook in the recoil springs (2x).
Assembly of the double wheels
Carry out the following steps on both
drive wheels.
i
13
. Remove screw
hexagonal screw M8 x 45
hexagonal nut
M8 self-locking
14
.
y Mount axle extender
y Re-insert screw and retighten nut.
15
. Push the wheel onto the axle extender
16
. Check the orientation of the wheel – the
tyre profiles should form a V viewed in the
direction of travel.
17
. Secure wheel with nut
Washer
Ø 10 x Ø 35 x 5
Hexagonal nut
M10 self-locking
18
. Press on protective cap
Assembly of Bowden cables
a) Bowden cable for throttle
y
Set the throttle lever on the right-hand
handlebar to the << START>> position.
19
. Push the governor lever on the carburettor
completely to the left (= start position).
20
.
y Insert the angled end of the Bowden
cable wire into the governor lever.
y Insert the Bowden cable sheath in the clip
y Gently push back the Bowden cable
sheath by hand until a resistance can be
felt.
Clamp the Bowden cable sheath in this
position.
Do not kink the Bowden cable during
assembly.
