MMD11 A

CONTROLS AND INDICATORS DIAGRAM (FRONT VIEW)

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

1. EJECT () Button

This Button is used for ejecting discs from the disc
Compartment when the source is DVD and the unit is powered up.

2. STOP (n) Button

This button is used to stop playback.

3. Source Select

Use to select one of the four sources:

DVD, AUX,AV1.

4. Picture Select (+)

To increase the level of selected picture controls.

5. Picture Select Button

Allows the user to enter the picture adjustment mode.

4
