ASUS A7V880 motherboard 2-19
EPP Version [1.9]
Appears only when the Parallel Port Mode is set to [EPP]. This item allows you
to to select the Parallel Port EPP version.
Configuration options: [1.9] [1.7]
ECP Mode DMA Channel [DMA3]
Appears only when the Parallel Port Mode is set to [ECP]. This item allows you
to set the Parallel Port ECP DMA.
Configuration options: [DMA0] [DMA1] [DMA3]
Parallel Port IRQ [IRQ7]
Sets the Parallel Port IRQ. Configuration options: [IRQ5] [IRQ7]
Onboard Game Port [Disabled]
Enables or disables the onboard GAME port.
Configuration options: [Disabled] [Enabled]
Onboard MIDI Port [Disabled]
Disables or sets the onboard MIDI port.
Configuration options: [Disabled] [300] [330]
2.4.4 PCI PnP
The PCI PnP menu items allow you to change the advanced settings for PCI/PnP
devices. The menu includes setting IRQ and DMA channel resources for either
PCI/PnP or legacy ISA devices, and setting the memory size block for legacy ISA
devices.
Advanced PCI/PnP Settings
WARNING: Setting wrong values in below sections
may cause system to malfunction.
Plug And Play O/S [No]
PCI Lantency Timer [64]
Allocate IRQ to PCI VGA [Yes]
Palette Snooping [Disabled]
PCI IDE BusMaster [Enabled]
IRQ3 [Available]
IRQ4 [Available]
IRQ5 [Available]
IRQ7 [Available]
IRQ9 [Available]
IRQ10 [Available]
IRQ11 [Available]
IRQ14 [Available]
IRQ15 [Available]
NO: Lets the BIOS
configure all the
devices in the system.
YES: Lets the
operating system
configure Plug and
Play (PnP) devices not
required for boot if
your system has a Plug
and Play operating
system.
Take caution when changing the settings of the PCI PnP menu items. Incorrect
field values may cause the system to malfunction.
