LG GWL2275YLQA - Manual (Page 21)

21
Separate the bin ( ) to upward.
Separate the upper rack of the refreshment
center and then pull out the refreshment
center cover ( ).
The refreshment center can be removed
by pulling it upwards. Refreshment
center
To remove the vegetable compartment
cover, pull out the vegetable compartment
a bit to the front
, lift the front part of the
vegetable compartment cover as shown by
, and take it out.
Vegetable
compartment
cover
• Be sure to remove parts from the refrigerator door when removing the vegetable
compartment, snack drawer and refreshment center cover.
NOTE
Care and maintenance
Insert the tool into the marked area (
ቢ) and
push the tool to disconnect.
Use the tool with the flat tip such as ( - ) screw
driver.
Turn the bulb counterclockwise. Max. 40 W
bulb for refrigerator is used and can be
purchased at a service center.
Lamp in
refrigerator
compartment
