Myron&Davis NV7TRV1 - Manual (Page 5)

Step 1. Remove the mounting bolts
on the driver’s and passenger’s side
Step 2. Carefully remove the radio. The
vents may or may not come with the radio
Step 1a. Remove factory radio
and disconnect .
Step 2a. Slide the vents off the radio
if they come out of the dash with the radio.
Step 1b. Remove the factory
radio.
Remove the OEM Radio and prepare the Myron and Davis Unit for installation by
following the steps below.
Note : Inspect all fasteners and brackets for damage. Replace as necessary before the
installation process is started
5 – Remove Factory Radio
Step 4. Remove the screws attaching the
clips to the factory radio.
Step 4a. There are two screws per clip. Re-attach the clips to the Myron and
Davis radio.
Step 3. Use the supplied brackets and
screws. DO NOT USE THE FACTORY SCREWS
Re -install the vents on to the Myron and
Davis radio.
