Atlantic Technology 254.1 SR - Manual (Page 7)

○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○
A
TECHNOLOGY
tlantic Models 251.1 LR, 253.1 C, and 254.1 SR
7
System 250.1 Specifications
Description 251.1 LR 253.1 C 254.1 SR
Type Sealed-box, 2-way Sealed-box, 2-way, Sealed-box, spatially-enhanced
Adjustable Timbre surround speaker
Drivers (2) 4" polypropylene (2) 4" polypropylene (2) 0.5" polypropylene
(1) 0.75" dome tweeter (1) 0.75" dome tweeter (2) 4" polypropylene
Frequency 50Hz – 20kHz 80Hz – 20kHz 80Hz – 20kHz
Response ( ±
3dB)
Nominal 8
Ω
8
Ω
8
Ω
Impedance
Sensitivity 90dB 90dB 90dB
Recommended 10 – 150W 10 – 150W 10 – 150W
Amplifier Power
Size (W x H x D) 6.0 x 13.0 x 8.5in 15.0 x 6.75 x 7.75in (including base) 9.5 x 10.5 x 6.4in
152 x 330 x 216mm 380 x 152–170 x 197mm 241 x 267 x 163mm
Weight (each) 12lbs 10.25lbs 8.1lbs
5.45kg 4.65kg 3.63kg
Specifications are those in effect at the time of printing. Atlantic Technology reserves the right to change
specifications or designs at any time without notice.
Dolby Stereo and Dolby Digital AC-3 are trademarks of Dolby Laboratories Licensing Corporation.
