If your dishwasher came with a non-slotted toe panel (H) and toe panel

brackets (J) follow these instructions:
Plug metal brackets (J) into openings on both sides of the base as shown.
Use screw (I) to mount metal brackets to the base as shown.

Tuck the pre-attached rubber apron behind the fingers on the metal

brackets as shown.
