Warmer Drawer
EW30WD55G S
High standards of quality at Electrolux Home Products, Inc. mean
we are constantly working to improve our products. We reserve the right
to change specifications or discontinue models without notice.
Electrolux Major Appliances, N.A.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-877-4electrolux (1-877-435-3287)
•
electroluxappliances.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
electroluxappliances.ca
EW30WD55G 07/11
© 2011 Electrolux Home Products, Inc.
Printed in the U.S.A.
30" Warmer Drawer / 30" Wall Oven Combination Specifications
•
To support Wall Oven when using in combination with Warmer Drawer,
two 3"-wide x 3/4"-thick planks must be installed as a base, capable of
supporting 200 Lbs. Do NOT use full base, since planks are necessary
to allow for proper air displacement.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.com for detailed instructions.
30" Warmer Drawer Specifications
•
Product Weight – 65 Lbs.
•
Voltage Rating – 120V / 450W / 60 Hz / 15 Amps
•
Connected Load (kW Rating) @ 120 Volts = 0.45 kW
(For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded for
safe operation.)
•
Amps @ 120V = 3.75 Amps
•
Recommended Circuit Breaker – 15 Amps
•
Full plywood base required, capable of supporting 100 Lbs.
•
Base must be level and cabinet front must be square.
•
Warmer Drawer can be used alone, or is approved to be used
in combination with any Electrolux Wall Oven. (Refer to Combination
Installation Specifications and drawing on this page.)
•
Warmer Drawer is approved to be used in combination with any
Electrolux Built-In Microwave and / or Electric Single Wall Oven. (Refer to
model-specific Combination Installation Specifications pages on web.)
23
5
/
8
" min.
24" max.
4
1
/
2
" min.
required
distance
to floor
9
7
/
8
" min.
10
1
/
4
" max.
28
1
/
2
" min.
28
3
/
4
" max.
Full plywood
base required to
support 100 lbs.
Warmer Drawer Stand-Alone Installation
Overall depth with drawer fully extended
(includes handle) – 45"
1
3
/
4
"
23
3
/
8
"
26
5
/
8
"
30"
11
1
/
4
"
Power cord
location (right
center rear)
Two 3" wide
x
3
/
4
" thick
planks must be
installed, capable
of supporting
200 lbs.
9
7
/
8
" min.
10
1
/
4
" max.
1
1
/
2
"
min.
*Critical dimension –
MUST be applied
**Electrical junction
box for Wall Oven
must be lower than
the Warmer Drawer
cutout
†
Maximum height
depends on critical
dimension (11
7
/
8
")
3"
max.**
Electrical
junction box
location
28
1
/
2
" min.
28
3
/
4
" max.
Bottom
of oven
cutout
11
7
/
8
"
min.*
23
5
/
8
" min.
24" max.
2"
min.
†
30
1
/
8
" min.
4" x 4"
opening
to route
armoured
cable
27
1
/
4
"
min.
27
5
/
8
"
max.
30" Warmer Drawer / 30" Single
Wall Oven Combination Installation
