MULTITASKER
400-0371-004 7
INSTALLING YOUR MT107-203 6
Step 1. Turn off power to the MultiTasker
enclosure and remove the input AC power
cord.
Step 2. Locate the MT107-104 currently installed
in the MultiTasker. Verify there is an
empty slot in the enclosure for the new
MT107-203 card.
The empty slot must be directly to the left
of the MT107-104 Matrix Engine. For
example, if the engine is installed in slot 8,
the input card should be installed in the
first empty slot number less than 8.
Step 3. Route the ribbon cables through the notch
in the add-on boards and connect to the
MT107-104 base assembly using the
special high-bandwidth cables provided
with the engine. Make sure the cable
connector is secured in the socket of the
input connector card.
Step 4. Attach the opposite end of the ribbon
cable to the card and carefully slide the
MT107-203 into the empty slot in the
MultiTasker enclosure.
Step 5. Secure the card by tightening the retainer
screws at the top and bottom.
Step 6. Connect the output of a Twisted Pair
transmitter to the inputs of the MT107-203
using ALTINEX’s special cable part
number MS8704TP.
Step 7. Restore AC power to the enclosure.
Step 8. The MT107-203 is now ready for
operation.
OPERATION 7
7.1 RS-232 CONTROL
The MT107-203 has many advanced
remote-control capabilities as part of an
MT107-104 Matrix Switcher. These capabilities
are accessible through standard RS-232
communication. The actual controlling can be
accomplished through a computer control
system or any other device capable of sending
RS-232 commands.
7.2 DESCRIPTION OF COMMANDS
Please see the MT107-104 User's Guide for a
full listing of commands available for the
MT107-203 as part of a MultiTasker Matrix
Switcher.
TROUBLESHOOTING GUIDE 8
We have carefully tested and found no problems in
the supplied MT107-203. However, we would like to
offer suggestions for the following:
8.1 NO DISPLAY
Cause 1: The source has a problem.
Solution: Check the source and make sure
that there is a signal present and all
source connections are correct. If
the source is working and there is
still no display, see Cause 2.
Cause 2: The input signal is not detected.
Solution 1: In AVSnap
®
, or other control
software, send the [SDI] command.
This command is detailed in the
MT107-104 User’s Guide. Verify a
signal is detected for the input
number in question. If a signal is not
detected, see Solution 2.
Solution 2: Verify the MT107-203 is connected
to the MT107-104 and that the cable
is in good condition. If a signal is
detected, see Cause 3. If there is no
signal detected, please
call
ALTINEX at (714) 990-2300.
