Install the tweeter into the extension housing by first threading the tweeter wires through the extension
housing and then installing the tweeter into the mounting slots of the housing and turn the tweeter
counterclockwise to lock the tweeter in place.
CAUTION: Do NOT overtighten the tweeter assembly.
Now feed the tweeter speaker wires through the front center of the woofer (where the aluminum bullet
was removed) As shown in the next illustration. Align and thread the coaxial tweeter assembly on the
threaded post in the center of the woofer. Rotate the coaxial tweeter assembly clockwise until snug.
Connect the tweeter wires to the tweeter output from the crossover.
Tweeter
Coaxial
Extension
Tweeter
Speaker
Wires
Mounting
Slots (qty 4)
Mounting
Tabs (qty 4)
