Description:
Based on the Atmel AT91M55800A
ARM7TDMI controller, the phyCORE-
ARM7/AT91 offers processing power
combined with low power consumption in
a minimum form factor (60x53 mm). The
AT91M55800A has a 32-bit RISC architecture
with a high-density 16-bit instruction set. A
large number of internal register banks
enable very fast command execution,
making the controller especially suited for
real-time applications. Up to 16 MB Flash and
8 MB SRAM in µBGA-housing populate the
module as external memory. The on-board
twin CAN controller provides two fully
configured 2.0B CAN interfaces, while a
CS8900A Ethernet controller supports data
transfer up to 10 Mbit/s. The standard
module configuration comes complete with
a JTAG interface for download of user code
and debugging purposes. Other chip-level
features include an 8-channel ADC with
10-bit resolution and a 2-channel DAC with
10-bit resolution. All applicable logic signals
are broken out at two dual-row high-
density (0.635 mm) connectors.
•
Subminiature SBC module
(60 x 53 mm)
•
Atmel AT91M55800A
ARM7TDMI 32-bit RISC
microcontroller
•
Flash: 1 to 16 MB µBGA-package
In System-Programmable (ISP)
•
SRAM: 512 KB to 8 MB µBGA-
package
•
RS-232, 10 Mbit/s CS8900A
Ethernet, JTAG interface
