Hot holding banquet carts – Alto-Shaam Halo Heat 1000-BQ2/96 User Manual
Page 2
ELECTRICAL
VOLTAGE
PHASE CYCLE
/
HZ
AMPS
kW
CORD
&
PLUG INCLUDED
125
1
50/60
12.8
1.6
NEMA
5-15
P
15A- 125V
PLUG
208-240 (
UL
)
1
50/60
6.5
1.6
NEMA
6-15
P
at 208
1
50/60
5.9
1.2
15A - 250V
PLUG
at 240
1
50/60
7.0
1.6
230
1
50/60
6.5
1.5
CEE
7/7
220-230V
PLUG
CAPACITY
240 lbs (109 kg)
MAXIMUM
VOLUME MAXIMUM
: 150
QUARTS
(190
LITERS
)
PLATES: (without plate carriers)
— 10" (254mm) with covers: 96
— 10-3/4" (273mm) with covers: 80
LARGER DIAMETER ITEMS WILL RESULT IN REDUCED PLATE CAPACITIES
PANS: Full-size and half-size pan combinations (per shelf)
— 12" x 20" (530mm x 325mm - GN 1/1): 2
— 12" x 10" (265mm x 325mm - GN 1/2): 4
ADDITIONAL WIRE SHELVES WITH SUPPORT CLIPS WILL ACCOMMODATE VARIOUS
COMBINATIONS OF
2-1/2" (65mm), 4" (100mm)
OR
6" (150mm)
DEEP PANS
SHELF CAPACITY: (per shelf, without covers)
— 10" (254mm) plates: 6
—
Shelves maximum: 16
SPACING ON CENTERS
3-5/32" (80mm)
C L E A R A N C E R E Q U I R E M E N T S
Full perimeter bumper accommodates all
clearance requirements.
INSTALLATION REQUIREMENTS
Cabinet must be installed level. It must not be
installed in any area where it may be affected by
steam, grease, dripping water, high temperatures,
or any other severely adverse conditions.
WEIGHT
NET
392 lb (178 kg)
SHIP
450 lb (204 kg)
CARTON
77"
X
44"
X
35"
DI M E N SI O N S
: (1956mm x 1118mm x 889mm)
O P T I O N S & A C C E S S O R I E S
Plate Carriers, chrome plated
(
EACH HOLD
4
PREPLATED MEALS
)
■
■
Uncovered "P" Carriers
DC-2868
Plate dia: 10" (254mm) max.
• 7-3/4" (197mm) min.
Vertical rung spacing: 2-5/8" (67mm)
CAPACITY
: 24
CARRIERS
, 96
PREPLATED MEALS
■
■
Covered "C" Carriers
DC-2869
Plate dia: 9-3/4" (248mm) max. • 7-3/4" (197mm) min.
Vertical clearance between top and bottom carrier: 11-5/8" (295mm)
CAPACITY
: 24
CARRIERS
, 96
PREPLATED MEALS
■
■
Shelf & Shelf Supports
(for each extra shelf)
1061/ 11533
Plate Carriers, chrome plated
(
EACH HOLD
4
PREPLATED MEALS
)
■
■
Uncovered "EP" Carriers
DC-23580
Plate dia: 12-1/2" (318mm) max.• 9-1/2" (241mm) min.
Vertical rung spacing: 2-5/8" (67mm)
CAPACITY
: 16
CARRIERS
, 64
PREPLATED MEALS
■
■
Covered "EC" Carriers
DC-23676
Plate dia: 12-1/2" (318mm) max.• 9-1/2" (241mm) min.
Vertical clearance between top and bottom carrier: 11-5/8" (295mm)
CAPACITY
: 16
CARRIERS
, 64
PREPLATED MEALS
■
■
Wire Shelf, chrome plated
SH-2835
210.0
O
5
9
-1
/1
6
"
(1
5
0
0
m
m
)
2
8
-7
/1
6
"
(7
2
2
m
m
)
6-3/16"
(156mm)
Electrical Connection
2-1/8" (54mm)
From Top
6
7
-1
/2
"
(1
7
1
4
m
m
)
37-9/16" (954mm)
30-7/16" (773mm)
30" (762mm)
I
o
I
o
8
-1
/1
6
"
(2
0
4
m
m
)
2
-1
/8
"
(5
4
m
m
)
1000-BQ2/96
HOT HOLDING BANQUET CARTS
(H x W x D)
W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE
: 262.251.3800 800.558.8744
U
.
S
.
A
./
CANADA
FAX
: 262.251.7067 800.329.8744
U
.
S
.
A
.
ONLY
www.alto-shaam.com
#46 - 1/08
P R I N T E D I N U
.
S
.
A
.
D U E TO O N G O I N G P R O D U C T D E V E L O P M E N T
,
S P E C I F I C AT I O N S A R E S U B J E C T TO C H A N G E W I T H O U T N O T I C E
15A-125V PLUG
NEMA 5-15P
20 AMP 125 VOLTS
PLUG, NEMA 5-20P
PLUG: NEMA 6-15P
15A, 250V
PLUG, CEE 7/7 (SCHUKO)
16 AMP 250V (#701410)
PLUG, CEE 7/7 (SCHUKO)
16 AMP 250V (#701410)
D I M E N S I O N S :
H x W x D
EXTERIOR
:
67-1/2" x 37-9/16" x 30-7/16"
(1714mm x 954mm x 773mm)
INTERIOR PER DOOR OPENING
:
53" x 28-1/4" x 25-1/2"
(1346mm x 718mm x 648mm)
15A-125V PLUG
NEMA 5-15P
20 AMP 125 VOLTS
PLUG, NEMA 5-20P
PLUG: NEMA 6-15P
15A, 250V
PLUG, CEE 7/7 (SCHUKO)
16 AMP 250V (#701410)
