AXIS 211M Installation Guide
Hardware overview
Dimensions
HxWxD = 44 x 88 x 172mm (1.7" x3.5" x 6.8")
Weight =244g (0.5 lb) (power supply not included)
Power
connector
Network
connector
I/O terminal
connector
DC-Iris control cable
Focus puller
Status indicator &
Internal microphone
Tele/wide puller
Power indicator LED
Network indicator LED
Serial number
Underside
Rear panel
Control button
Audio in Audio out
