Axis Communications 207 - Manual (Page 24)

24 AXIS 207 - Event Configuration
Event Configuration
An event in the AXIS 207 is when a trigger is activated, causing a certain action to be
performed. The event is the set of parameters (or conditions) that specifies how and when
which actions will be performed. A common event is when the camera uploads images,
triggered by an alarm.
This section describes how to configure the AXIS 207 to perform certain actions when an
event (e.g. an alarm) occurs.
Triggered by...
Input Port
This describes the state that the
input must be in for an event to
be triggered e.g. a door sensor
connected to the camera’s input
port. If the door sensor is active,
an event is triggered.
Motion Detection
Movement in a motion detection
window can be used to trigger an event. Select the motion detection window from the
drop-down list and specify whether to trigger the event when motion stops or starts. For
information on how to set up motion detection windows see Motion Detection, on page 26.
Manual Trigger
This option makes use of the action buttons on the live view page, which are used to start
or stop the event manually, e.g. activate an alarm connected to the camera’s output port.
Alternatively the event can be triggered via the product's API (Application Programming
Interface).
When Triggered...
Upload images/video - Enabling this option allows images or video to be uploaded to
different destinations, via FTP, via HTTP, or in email messages. Check the box to enable
and select the required upload method. See the online help for more information on the
settings required for upload servers and email.
Note:
Mail servers must be configured under System Options > Network > SMTP
File format - Enter the file format (MPEG-4 or JPEG) you wish to upload. Check the
Include audio checkbox if audio is to be included (MPEG-4 only).
